CAB24/4PS6ACMPWHIBOX
LEVITON 11142628 RDT Cat 6A U/UTP Cable, CMP, White, 1000 ft (305 m), TEKPAK™ box
Description
RDT cable features a reduced diameter of 0.230" (vs. 0.275" average Cat 6A cable), creating better flexibility, optimized cable management, and improved tray-fill ratio for high-density installations. It offers excellent signal isolation, with PoE and Alien Crosstalk performance that exceeds standards, making it an excellent choice for 802.11ac wireless, HD video and IP security. The cable’s insulated metallic isolation wrap provides superior heat management and noise-cancelling performance, preventing electrical energy from running along the shield and eliminating the need for grounding. The electrical performance is independently verified by ETL (Intertek) as part of the LM Verified Performance program
Specifications
| Brand Name | Leviton | Sub Brand | LM-RDT™ |
| Item Name | Category 6a Cable | Type | CMP, U/UTP |
| Wire Gauge Size | 23 AWG | Conductor Material | Copper |
| Length | 1000 ft | Insulation Material | Thermoplastic |
| Jacket Color | White | Bend Radius | 0.92 in |
| Outside Diameter | 0.23 in | Capacitance | 5.1 nF/100 m |
| Maximum Delay Skew | 45 Nanosecond/100 m | Resistance | 9.38 O/100 m |
| Weight | 31 lb/1000 ft | Standards | ANSI/TIA-568.2-D Category 6a, RoHS Compliant, UL Listed |
| Application | For 802.11ac Wireless, HD Video and IP Security |
Packages
| 1 - UNIT - 1 |
