paspt5362bl

PASS & SEYMOUR PT5362BL 20Amp 125V NEMA 5-20R PlugTail Spec Grade Duplex Receptacle, Blue

Price $18.03 / EA
Inventory
Available for backorder
Unavailable for pick up Abbotsford
Qty EA
Manufacturer:PASS & SEYMOUR
Manufacturer #:PT5362BL

Description

PlugTail® Spec Grade Duplex Receptacle 20amp 125volt.FEATURES AND BENEFITS:• RoHS Compliant• .036 inch thick, brass, triple-wipe power contacts for lasting retention.• Plated steel wrap strap design for maximum durability and corrosion resistance.• No exposed terminals create a finger safe application before, during, and after installation.• Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.• Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.• Crimped and welded contacts.• Large brass contacts snugly terminate on device blade terminals.• Pre-stripped connector leads fasten to conductors, easier than standard pigtails.• Auto-ground clip assures positive ground.

Specifications

Brand Name Pass & Seymour Sub Brand PlugTail®
Item Name Receptacle Type Duplex, Specification Grade
Grade Federal Specification Voltage Rating 125 V
Amperage Rating 20 A Number of Poles 2
Number of Wires 3 NEMA Rating 5-20R
Conductor Size 12 AWG Material Nylon Face, PVC Body
Color Blue Dielectric Strength 2000 V
Grounding Grounding Contact Material 0.036 in T Brass
Dimensions 1-1/2 in W x 5/8 in D x 3.281 in H Mounting Type Wall
Temperature Rating 60 °C Maximum Continuous, -40 °C Minimum without Impact Environmental Conditions UL 94 Requirements, V2 Rated Flammability
Standards cUL E140596, UL E140596, UL498, cULus Listed, RoHS Compliant UPC 785007091670

Packages

1 - UNIT - 1 10 - UNIT - 10 100 - UNIT - 100 4400 - SKID - 4400
