orttj60036
MIDDLE ATLANTIC TJ600-36 Ortronics Clarity 6 TracJack, T568A/B, 180 degree, Blue
orttj60036
MIDDLE ATLANTIC TJ600-36 Ortronics Clarity 6 TracJack, T568A/B, 180 degree, Blue
Price
$19.99
/ EA
Inventory
Available for backorder
Unavailable for pick up
Abbotsford
Manufacturer:LEGRAND
Manufacturer #:TJ600-36
Description
Clarity 6 TracJack, ETL verified to TIA Category 6 component specification. Front-loading and front removable. New universal T568A/B wiring label and tapered wiring towers simplify termination. Center tuned to Clarity 6 patch cords for optimum performance
Specifications
| Brand Name | Ortronics | Sub Brand | TracJack® |
| Item Name | Modular Jack | Type | Jacks And Modules |
| Cable Type | Category 6 | Number of Positions | 8 |
| Termination Style | RJ-45 | Contacts | Beryllium Copper/Phosphor Bronze |
| Color | Blue | Series/Model | Clarity |
| Cable Size | 26-22 AWG | Number of Contacts | 8 |
| Material | High Impact Thermoplastic | Temperature Rating | -10 to 60 °C |
| Dimensions | 0.73 in L x 1.06 in W x 0.92 in H | For Use With | Faceplates and Housings |
| Standards | Buy American Act Compliant, ETL Listed, IEEE 802.3AF/802.3AT, 802.3 BT Type 3 and Type 4, FCC Part 68, Subpart F and IEC-603-7 Compliant, TIA-568.2-D, UL 1863, UL File Number E131600, UL 94V0 Flammability Rating, RoHS 2011/65/EU Compliant | Application | For Commercial, Industrial |
| UPC | 662875437871 |
Packages
| 1 - UNIT - 1 | 100 - UNIT - 100 |
