SIEMENS HFC226NA SWITCH 600A 2PH 3W 240VFUSIBLE HD TYPE 1
Description
CSA Heavy Duty Safety Switch, Fusible, 2 Poles, 240V, 600A, Type 1, With Neutral - Service Entrance Rated
Specifications
Brand Name | Siemens | Sub Brand | VBII |
Item Name | Safety Switch | Type | Heavy-Duty, Single Throw |
Voltage Rating | 240 V | Amperage Rating | 600 A |
Number of Poles | 2 | Number of Wires | 3 |
Connection Type | Mechanical Lugs | Operating Cycles | 5000 |
Series/Model | Series A | Frequency Rating | TRUE |
Housing Material | Steel | Mounting Type | Surface |
NEMA Rating | NEMA 1 | Temperature Rating | -29 to 85 °C |
Standards | CSA Certified, UL 98 Listed | Application | For Service Entrance/Loads |
UPC | 887621872946 |
Packages
1 - UNIT - 1 |
