SIEHFC365NA
SIEMENS HFC365NA VBII Fusible, Type VBII Heavy Duty Safety Switch 400 A, 600 V, 3 P, Steel NEMA 1
Description
CSA Heavy Duty Safety Switch, Fusible, 3 Poles, 600V, 400A, Type 1, With Neutral - Service Entrance Rated
Specifications
| Brand Name | Siemens | Sub Brand | Safety Switches |
| Item Name | Heavy Duty Safety Switch | Type | Fusible, Type VBII |
| Voltage Rating | 600 V | Amperage Rating | 400 A |
| Number of Poles | 3 | Number of Wires | 4 |
| Contact Configuration | Single Throw | Connection Type | Mechanical Lug, Screw |
| Operating Cycles | 6000 | Frequency Rating | TRUE |
| Housing Material | Steel | Mounting Type | Surface |
| NEMA Rating | NEMA 1 | Temperature Rating | -29 to 85 °C |
| For Use With | Front Mounting 4 Hole | Standards | UL 98 Listed, CSA Certified |
| Application | Disconnecting Mean for Service Entrance/Loads | UPC | 887621873035 |
Packages
| 1 - UNIT - 1 |
